B-380 Phase Contrast

OPTIKA B-380 Series phase contrast microscopes are equipped with a 5-position dedicated rotating condenser (for brightfield, 10x/20x, 40x and 100x phase diaphragms, and a darkfield position for dry objectives), the state-of-the-art, exclusive X-LED³ lighting source (3.6W) and the high quality, flat images captured with W-PLAN optics.

The exclusive Automatic Light Control (ALC Models) is available to ensure unparalleled performance and comfort during use.

Phase contrast is widely used on transparent, non-stainable, samples like culture of living cells, microorganisms and subcellular particles to enhance the contrasts of transparent and colorless objects, revealing many cellular structures that are not visible with a simple brightfield microscope.



Related Literature:







00000000

PHASE CONTRAST

Phase-contrast microscopy is a particular technique applied in transparent, non-stainable, samples like culture of living cells, microorganisms, lithographic patterns, latex dispersions, fibers, asbestous and subcellular particles. It reveals many cellular structures that are not visible with a simple brightfield microscope.

B-380 Series is available also in different techniques (darkfield, brightfield, fluorescence, polarized light, material science).

Images are for illustrative purposes only

CONDENSER SUITABLE FOR DARKFIELD

OPTIKA B-380 phase contrast microscopes are equipped with a 5-position dedicated rotating condenser for brightfield (standard use), phase contrast (10x/20x, 40x and 100x phase diaphragms), and a darkfield position for dry objectives

Improving The Most Important Aspects of Microscopy Experience

HIGH QUALITY, FLAT IMAGES CAPTURED WITH OUTSTANDING OPTICS

» Binocular and trinocular heads with 20mm field number
» True infinity optical system available (IOS)
» Fully centerable condenser for precise light control

LABORATORY GRADE OPTICS

» N-PLAN objectives, high numerical apertures
» Planachromatic optics with more than 90% flat field
» Significant optical correction, low field curvature and distortion

X-LED³ Exclusive Lighting Source

Achieve bright images, improved colour fidelity, pure white colour temperature, incredibly low energy consumptions and longer lifespan with the unique X-LED³ technology, able to double the light intensity for incomparable performance. Relevant money and energy saving thanks to the incredibly low energy consumptions which allows you to cut the electricity bills by 90%!

X-LED³ – Two Times Brighter Than Any Other

STATE-OF-THE-ART ILLUMINATION SYSTEM

» Unmatched colour fidelity and brightness of your specimen
» Special technology, able to double the light intensity
» Constant pure-white colour temperature (6.300K)

CUT ELECTRICITY BILLS BY 90%

» Money & energy saving
» Low power consumption, only 3.6W
» LED long lifetime (65,000 hours = 25 years at 8 hours/day usage)

xled3

ALC – Automatic Light Control, Only Available At OPTIKA

Incomparable Comfort With The Exclusive Automatic Light Control (ALC)
Automatic light intensity regulation. Seamless operation with instant brightness adjustment, automatically performed by the microscope for you. No matter if the aperture of the dia­phragm changes, if another objective is used, and if the opacity of the sample is different…the microscope will set the light for you according to your preferences.
On B-382PL-ALC, B-382PLi-ALC, B-382PH-ALC & B-382PHi-ALC.

3-STEPS EASY SETTING

» Choose the light intensity you prefer
» Press the button and set the light
» Change the objectives or close the diaphgram aperture: the
microscope will keep the same light intensity!

AUTOMATIC LIGHT CONTROL & ADJUSTMENT

» When another objective is used
» When the aperture diaphragm changes
» When processing another sample with different opacity

Safe And Convenient Operations

The rackless stage has been designed with a belt-driven mechanism that
allows a smooth movement without any protruding part.
This design gives you a more compact solution and lowers any risk
of injury after accidentally hitting the rack with your hands.

A New Frontier in Ergonomic Product Design

ELEGANT DESIGN WITHSTANDING EVERYDAY USE

» Ergonomic positioning of the main controls
» Long lasting mechanical parts, rackless moving stage
» Maintenance-free illumination system

EASY TO CARRY, LIGHT, STEADY

» Improving productivity, reducing fatigue
» Increases job accuracy and quality
» Easily portable, with comfortable handgrip

Large Specimen View (20mm Field Number)

Enjoy a 20mm field of view ensures you to gain peripheral view and comfort when observing the specimen. This means more efficient inspections and allows a natural and easy view, particularly needed in a laboratory environment.

B-382PH-ALC_model

Model: B-382PH-ALC


Phase contrast and brightfield binocular microscope with W-PLAN PH objectives, moving stage and combining the exclusive X-LED³ with ALC for great-looking, rich and high-quality specimen view.

B-383PH_model

Model: B-383PH


Phase contrast and brightfield trinocular microscope with W-PLAN PH objectives, moving stage and the exclusive X-LED³ for incredibly bright illumination.

line
B-382PHi-ALC_model

Model: B-382PHi-ALC


Phase contrast and brightfield binocular microscope with IOS (infinity corrected) W-PLAN PH objectives, rackless moving stage and combining the exclusive X-LED³ with ALC for great-looking, rich and high-quality specimen view.

B-383PHi_model

Model: B-383PHi


Phase contrast and brightfield trinocular microscope with IOS (infinity corrected) W-PLAN PH objectives, rackless moving stage and the exclusive X-LED³ for incredibly bright illumination.

line



Some application examples showing the extreme versatility of B-380 Series in its several available configurations. Applications in education, biology, botany and simple material analysis. This series represents the best entry-level solution for the routine laboratory.
