Head: Monocular, 45° inclined; 360° rotating.
Eyepiece: WF10x/18 mm, secured by screw.
Nosepiece: Triple ball bearings revolving nosepiece.
– Achromatic 4x/0.10
– Achromatic 10x/0.25
– Achromatic 40x/0.65.
All with anti-fungus treatment.
Specimen stage: Fixed stage, 120×110 mm, with sample clips.
Focusing: Separate coarse and fine focusing mechanism with limit stop to prevent the contact between objective and specimen.
Condenser: N.A. 0.65 with iris diaphragm.
Illumination: 1 W LED. Color temperature: 6,300 K. 100-240Vac/12Vdc external power supply.
