Observation mode: Brightfield, phase contrast and darkfield (dry).
Head: Binocular, 30° inclined, 360° rotating (when ALC cable is unplugged).
Interpupillary distance: Adjustable between 48 and 75 mm.
Dioptric adjustment: On the left eyepiece tube.
Eyepieces: WF10x/20 mm, high eye-point and secured by screw.
Nosepiece: Quintuple revolving nosepiece, rotation on ball bearings.
IOS W-PLAN PH 10x/0.25
IOS W-PLAN PH 20x/0.40
IOS W-PLAN PH 40x/0.65
IOS W-PLAN PH 100x/1.25 (Oil)
All with anti-fungus treatment.
Specimen stage: Double layer rackless mechanical stage, 233×147 mm, 78×54 mm X-Y range.
Focusing: Coaxial coarse (adjustable tension) and fine focusing mechanism with limit stop to prevent the contact between objective and specimen.
Condenser: Phase condenser (10x/20x, 40x, 100x) with darkfield (dry) and brightfield.
Illumination (Fixed Koehler type): X-LED3 with white 3.6 W LED (6,300K) and brightness control.
